Welding set PATON™ ProMIG-350-15-4-400V WK

The ProMIG-350 incorporates modern technology to enhance the welding experience. Features precise control of voltage rise and fall times, as well as wire feed speed regulation, ensuring smooth transitions and minimal spatter

This is a professional machine, designed for semi-automatic welding MIG/MAG, manual arc welding MMA, καθώς και TIG DC, with shielding gases or their mixtures. The ProMIG-350 Features a fully digital management system, offering high flexibility and precise control over welding conditions.

The increased efficiency at the rated current of the 350A allows the use of electrodes with diameters from 1,6 mm έως 6 mm, as well as semi-solid welding wires with a diameter of 0,6 to 1,2 mm. Thanks to its dual design, the power source can be easily detached from the wire feed unit, greatly enhancing portability and usability in various operations. MMA and TIG modes.

Rated power supply voltage 50/60 Hz	3×400 V
Rated power supply current	16 – 18 A
Rated welding current	350 A
Maximum operating current	450 A
Operating load factor %	70% – 350 А
Operating load factor %	100% – 290 А
Power supply voltage range	±15% V
Welding current control range	15 – 350 A
Welding current control range	12 – 30 V
Wire feeding speed control range	2,0 – 16 m/min
Diameter of a stick electrode	1,6 – 6,0 mm
Number of pressure rolls	4
Diameter of electrode wire	0,6 – 1,4 mm
Coil weight, not more than	≤18 kg
Welding processes with a pulse welding mode	MMA/TIG/MIG/MAG
Function “Hot-Start”	Adjustable
Function “Arc-Force”	Adjustable
Function “Anti-Stick”	Automatic
Reduction of open-circuit voltage	ON / OFF
Open-circuit voltage	12 / 75 V
Welding arc starting voltage	110 V
Rated consumed power	10,5 … 11,8 kVA
Maximum consumed power	15,0 kVA
Efficiency coefficient	90%
Cooling	Automatic
Operating temperature range	–25 … +45 ºС
Fulfilled standards:	EN 60204 – 1:2006
	EN 60974 – 1:2012
	EN 60974 – 10:2014
Overall dimensions (length, width, height)	540 х 360 х 400
Weight	23,9
Protection class*	IP 33
