| Supply voltage 50/60 Hz | 230 V |
| Required nominal current from the mains | 25 A |
| Nominal welding current | 200 A |
| Maximum welding current | 200 A |
| Voltage change intervals, V | 190 – 260 V |
| Welding current adjustment intervals | 5- 200 A |
| Basic operating mode | TIG AC/DC |
| Additional operating mode | RIV, MMA |
| Welding current regulation limits TIG AC/DC mode | 5 – 200 A |
| Idle voltage | 65 V |
| Energy efficiency | Not less than 80 % |
| Duty cycle with welding current 126 (DC) | 100% |
| Welding cycle 200 A (DC) | 40% |
| Duty cycle at 140 A (AC) welding current | 100% |
| Duty cycle for welding current 200 A (AC) | 50% |
| Nominal power consumption | 6,3 kVA |
| Non-contact arc ignition (HF) | YES |
| Welding current indicator | YES |
| Memorizing modes of operation | 10 programmes |
| Alternating current frequency | 15 – 250 Hz |
| Polarity balance in TIG AC/DC welding | 15 – 90 % |
| Burner button mode, TIG AC/DC | 2ะข, 4ะข |
| Time of the shielding gas supply before welding | 0,1 – 25 s |
| Welding time of the protective gas supply | 0,1 – 25 s |
| RIV method pulse time adjustment | 0,5 – 5 s |
| Peak current regulation in the RIV method | 5 – 200 A |
| Starting current control | 5 – 185 A |
| Adjusting the time of the current rise | 0 – 15 s |
| Adjusting the time of the current drop | 0 – 25 s |
| End current regulation | 5 โ 185 A |
| Dimensions (length, width, height), mm: | 465 x 190 x 350 |
| Standards met: | EN 60204 โ 1:2006 / EN 60974 โ 1:2012 / EN 60974 โ 10:2014 |
| Weight of the welder | 14,7 kg |
| Degree of protection | IP21 |
