STAR DRAIN 65 - PVC CHANNEL DRAIN WITH ALUMINIUM GRATING
Request a quote
Description:
Manufactured from high quality extruded PVC plastic and aluminium grating, Alusthetic Threshold Drains helps eliminate water pooling at property entrances, grounds and surrounding areas; the heel guard grating is suitable for pedestrian traffic. With it's discreet slim 65mm width, this boasts a desirable channel for any threshold, patio or non trafficked application.
Materials:
- The grills are made of anodized aluminum
- The channels and fittings are made of PVC
Features:
Features Easy to install Simple connection to standard underground drainage via 50mm or 80mm outlet Removable heel guard Fully compliant and certified to load class A 15 BS EN 1433:2002 Compliant with Part M of the Build Regulations for England and Wales
Tech. Spec
Channel Length: 1000mm (1M) | Channel Height: 100mm | Channel Width: 65mm
Available grating profile; Anodized Aluminium Silver & Anodized Aluminium Black
Description body: PVC extruded profile
Manufactured and monitored according to standard NBN EN 1433:2002
| Code | Description | External Description (mm) | Clear Opening (mm) |
| IASLT-65/100-B | ΜΕ ΣΧΑΡΑ ΑΛΟΥΜΙΝΙΟΥ ΜΑΥΡΗ | 65X1000X100 | 50x1000x90 |
| IASLT-65/100-G | ΜΕ ΣΧΑΡΑ ΑΛΟΥΜΙΝΙΟΥ ΓΚΡΙ | 65X1000X100 | 50x1000x90 |
| Colour | Μαύρο, Γκρί |
|---|
