Rated power supply voltage, V |
380/400 |
Rated current consumption from the mains phase, А |
17,7 |
Rated welding current (A) |
350 |
Maximum operating current, A |
450 |
Operating load factor |
70% |
Power supply voltage range (V) |
±15% |
Welding current control range (A) |
50 – 350 |
Dimensions L / W / H |
390 х 145 х 335 |
Diameter of a stick electrode, mm |
2-6 |
Warranty period, month |
36 |
«Hot-Start» |
Auto |
«Arc-Force» |
Auto |
«Anti-Stick» |
Auto |
Idling voltage, V |
up to 80 |
Arc ignition voltage, V |
110 |
Rated power consumption, kVA |
11,7 |
Maximum consumption,power kVA |
15,2 |
Efficiency, % |
90 |
Cooling |
Forced |
Gross weight, kg |
14 |
Weight, kg |
9,8 |
Protection rate |
IP33 |
