PATON™ ECO-250
Request a quote
The PATON ECO inverters they are ergonomic and compact machines, designed for DC arc welding (MMA), with a rated current of up to 160A, making them the ideal solution for those who need portability, reliability, and high performance.
The PATON ECO support diameter electrodes 1.6 mm to 5.0 mm, with a duty cycle of up to 40%. Thanks to the automatic functions Anti-Stick, Arc Force and Hot-Start, they are easy to use and user-friendly, regardless of experience level.
These are versatile welders, suitable for a wide range of applications – from home projects to small workshops – ensuring consistent and reliable performance even during extended use. Thanks to the modern IGBT semiconductors, the PATON ECO reduces electromagnetic interference and maximizes efficiency, delivering strong and stable welding performance.
Technical Specifications
| Rated power supply voltage, V | 220/230 |
| Rated current consumption from the mains phase, А | 32 |
| Rated welding current (A) | 250 |
| Maximum operating current, A | 300 |
| Operating load factor | 40% |
| Power supply voltage range (V) | 170-260 |
| Welding current control range (A) | 32 – 250 |
| Diameter of a stick electrode, mm | 1,6-5 |
| Warranty period, month | 60 |
| «Hot-Start» | Auto |
| «Arc-Force» | Auto |
| «Anti-Stick» | Auto |
| Idling voltage, V | to 80 |
| Arc ignition voltage, V | 110 |
| Rated power consumption, kVA | 7 |
| Maximum consumption,power kVA | 8,8 |
| Efficiency, % | 90 |
| Overall dimensions, WxLxH, mm | 110х270х240 |
| Gross weight, kg | 8 |
| Weight, kg | 4,35 |
| Protection rate | IP21 |
